Application and application scenarios:
Planetary ball mill is a device for mixing, fine grinding, sample preparation, new product development and small batch production of high-tech materials. There are four ball mill tanks. When the turntable rotates, the ball mill tanks rotate around the axis of the turntable while rotating around their own axis, making planetary movement. The grinding balls in the tank collide with each other in high-speed movement, grinding and mixing samples.
The planetary ball mill is suitable for wet and dry grinding and refining of hard, medium hardness, brittleness and fiber materials, the fineness of the sample can be less than 100nm, and can also be used for grinding of solids in suspension, sample mixing and homogenization treatment and metal alloying, etc., which can achieve excellent results.
Features of this machine:
1. Four cans grinding, high efficiency, can handle 4 samples at the same time
2. Stable speed, fine grinding
3. Fully closed ball mill tank to avoid cross contamination,
4. Nano-level grinding, the minimum particle size of the grinding product can reach 0.1 micron
5. The appearance is made of sheet metal spray, with heat dissipation hole on the back to facilitate motor heat dissipation and extend service life
6. Low noise: noise decreased by 15-20DB year-on-year
7. Intelligent motor configuration: wide speed regulation, large torque, constant speed, longer life, wide application range
Applicable scene:
1. Used in colleges and universities
2. Research institutions and enterprise laboratories will quickly grind the research sample to the gelatinous fineness in batches, and mix, homogenize and disperse
3. Widely used in geology, minerals, metallurgy, electronics, building materials, ceramics, chemical industry, light industry medicine, beauty, environmental protection and other scientific research and industry sectors.
